2nd Battery Kit for 3rd Gen Revels
2nd Battery Kit for 3rd Gen Revels
Our 2nd battery kits for 3rd Generation Revels are for folks that JUST want a nicely integrated second battery without a larger alternator, bigger inverter, cleaned up control panel, etc. This is kit is recommended for DIY friendly folks that are into major van surgery. The full instructions are available below so you can take a look at what is entailed.
There are two varieties of this product:
- The full kit containing the mounting parts and the battery
- Just the mounting kit with no battery
If you already have a battery that was installed in the main garage area and want to hide it and integrate it into the existing system, you can buy the mounting kit only.
See the Installation Instructions.
Kit Contents
Kit Contents
• 1x 320 Ah Lithionics battery (if included in selected configuration)
• 2x battery trays. Sheet metal which bolts to the wall of the van as well as the floor/shelf. These batteries are HEAVY (70+ lbs) and need a secure mount. It also structurally ties the "shelf" that the current battery sits on into the wall so that the shelf does not come loose as commonly happens.
• A shorter powder-coated compartment/cubby to hide the lower battery and replace the existing larger aluminum cubby.
• A remote switch for the lower battery.
• An inverter disconnect knob elimination kit to simplify wiring and remove potential failure points.
• New wires for both batteries.
• All hardware, zip ties, etc. needed for the installation
